// Arduino IoT Shower
// vgmlr
// A1 Temp Head
// 0 Cap 10M
// 1 Cap 1K
// 2 3 4 5 11 12 LCD
// 6 LED
// 7 Hot
// 8 Valve
// 9 Cold
// Libraries
#include "SPI.h"
#include "WiFi101.h"
#include "LiquidCrystal.h"
#include "Servo.h"
#include "CapacitiveSensor.h"
// WiFi
char ssid[] = "NETWORK";
char pass[] = "PASSWORD";
int keyIndex = 0;
int status = WL_IDLE_STATUS;
WiFiServer server(80);
// ThingSpeak
char thingSpeakAddress[] = "api.thingspeak.com";
String APIKey = "XXXXXXXX"; // API
const int updateThingSpeakInterval = 10 * 1000; // Interval
long lastConnectionTime = 0;
boolean lastConnected = false;
WiFiClient client;
// LCD
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);
// Servos
Servo hot;
Servo valve;
Servo cold;
int openturn = 0;
int closeturn = 180;
int noturn = 90;
// Servo Position Delays
int hotdelay = 450;
int valvedelay = 700;
int colddelay = 300;
// Temperature
int temptub = A0;
int temphead = A1;
int templow = 0;
int temphigh = 0;
int tempc = 0;
int pretempf = 0;
// Temperature Variable
int settemp = 42;
int preptemp = 0;
int tempvarlow = 0;
int tempvarhigh = 0;
// Map Variables
int lowvol = 400;
int highvol = 1005;
int lowc = 56;
int highc = 131;
// On Off Button
CapacitiveSensor   onoffbutton = CapacitiveSensor(0, 1);
int touchpeak = 150;
// State
// 0 = Off
// 1 = Turn On
// 2 = On
// 3 = Shut Off
int state = 0;
void setup() {
  Serial.begin(9600);
  // Servos
  hot.attach(7);
  valve.attach(8);
  cold.attach(9);
  hot.write(90);
  valve.write(90);
  cold.write(90);
  // Temperature
  pinMode(temptub, INPUT);
  pinMode(temphead, INPUT);
  // LCD
  lcd.begin(16, 2);
  lcd.clear();
  // WIFI Connection
  while ( status != WL_CONNECTED) {
    lcd.setCursor(0, 0);
    lcd.print("Connecting...");
    lcd.setCursor(0, 1);
    lcd.print(ssid);
    Serial.print("Connecting Network: ");
    Serial.println(ssid);
    status = WiFi.begin(ssid, pass);
    delay(10000);
  }
  server.begin();
  lcd.clear();
  printWifiStatus();
  delay(3000);
  lcd.clear();
}
void loop() {
  // WiFi Server Page
  if (state == 0) {
    WiFiClient client = server.available();
    if (client) {
      String currentLine = "";
      while (client.connected()) {
        if (client.available()) {
          char c = client.read();
          Serial.write(c);
          if (c == '\n') {
            if (currentLine.length() == 0) {
              client.println("HTTP/1.1 200 OK");
              client.println("Content-type:text/html");
              client.println();
              client.print("");
              client.print("
");
              client.print("
");
              client.print(settemp);
              client.print("
");
              client.print("");
              client.print("");
              client.print("");
              client.print("");
              client.println();
              break;
            }
            else {
              currentLine = "";
            }
          }
          else if (c != '\r') {
            currentLine += c;
          }
          if (currentLine.endsWith("GET /U")) {
            settemp = settemp + 1;
          }
          if (currentLine.endsWith("GET /D")) {
            settemp = settemp - 1;
          }
          if (currentLine.endsWith("GET /S")) {
            state = 1;
          }
        }
      }
      client.stop();
    }
  }
  // On Off Button
  long touch = onoffbutton.capacitiveSensor(30);
  if (touch > touchpeak) {
    if (state == 0) {
      state = 1;
    }
    else if (state == 2) {
      state = 3;
    }
  }
  // Update ThingSpeak
  if (state == 1 || state == 2) {
    temphigh = analogRead(temphead);
    pretempf = map(temphigh, lowvol, highvol, lowc, highc);
    tempc = (pretempf - 32) * 5 / 9;
    String headtemperature = String(tempc, DEC);
    String runtime = String(state, DEC);
    if (millis() - lastConnectionTime > updateThingSpeakInterval) {
      updateThingSpeak("field1=" + runtime + "&field2=" + headtemperature);
    }
  }
  // State Operation
  if (state == 1) {
    turnon();
  }
  else if (state == 2) {
    shower();
  }
  else if (state == 3) {
    turnoff();
  }
}
void printWifiStatus() {
  Serial.print("SSID: ");
  Serial.println(WiFi.SSID());
  IPAddress ip = WiFi.localIP();
  Serial.print("http://");
  Serial.println(ip);
  long rssi = WiFi.RSSI();
  Serial.print("RSSI: ");
  Serial.print(rssi);
  Serial.println(" dBm");
  lcd.setCursor(0, 0);
  lcd.print(WiFi.SSID());
  lcd.setCursor(0, 1);
  lcd.print(ip);
}
void updateThingSpeak(String tsData) {
  if (client.connect(thingSpeakAddress, 80)) {
    client.print("POST /update HTTP/1.1\n");
    client.print("Host: api.thingspeak.com\n");
    client.print("Connection: close\n");
    client.print("X-THINGSPEAKAPIKEY: " + APIKey + "\n");
    client.print("Content-Type: application/x-www-form-urlencoded\n");
    client.print("Content-Length: ");
    client.print(tsData.length());
    client.print("\n\n");
    client.print(tsData);
    lastConnectionTime = millis();
  }
}
void turnon() {
  // LCD Temperature Display
  lcd.clear();
  lcd.setCursor(0, 0);
  lcd.print("Set Temp:");
  lcd.setCursor(10, 0);
  lcd.print(settemp);
  lcd.setCursor(0, 1);
  lcd.print("Current:");
  lcd.setCursor(9, 1);
  lcd.print("0");
  // Hot Open Valve Tub Cold Closed
  hot.write(180);
  delay(hotdelay);
  hot.write(90);
  delay(2000);
  preptemp = settemp - 2;
  // Wait For Temp
  while (preptemp > tempc) {
    templow = analogRead(temptub);
    pretempf = map(templow, lowvol, highvol, lowc, highc);
    tempc = (pretempf - 32) * 5 / 9;
    lcd.setCursor(9, 1);
    lcd.print(tempc);
    String headtemperature = String(tempc, DEC);
    if (millis() - lastConnectionTime > updateThingSpeakInterval) {
      updateThingSpeak("&field2=" + headtemperature);
    }
  }
  // Hot Open Valve Tub Cold Open
  cold.write(180);
  delay(colddelay);
  cold.write(90);
  // Delay For While Statement
  delay(2000);
  // Wait For Temp
  while (preptemp > tempc) {
    templow = analogRead(temptub);
    pretempf = map(templow, lowvol, highvol, lowc, highc);
    tempc = (pretempf - 32) * 5 / 9;
    lcd.setCursor(9, 1);
    lcd.print(tempc);
    String headtemperature = String(tempc, DEC);
    if (millis() - lastConnectionTime > updateThingSpeakInterval) {
      updateThingSpeak("&field2=" + headtemperature);
    }
  }
  // Hot Open Valve Head Cold Open
  valve.write(180);
  delay(valvedelay);
  valve.write(90);
  // Set State On
  state = 2;
  // Update State ThingSpeak
  String runtime = String(state, DEC);
  updateThingSpeak("field1=" + runtime);
}
void shower() {
  // Get Temp Shower Head
  temphigh = analogRead(temphead);
  pretempf = map(temphigh, lowvol, highvol, lowc, highc);
  tempc = (pretempf - 32) * 5 / 9;
  // Print Shower Temp
  lcd.setCursor(9, 1);
  lcd.print(tempc);
  // Set Temperature Leeway
  tempvarlow = settemp - 2;
  tempvarhigh = settemp + 2;
  // Adjust Temperature
  if (tempc < tempvarlow) {
    cold.write(0);
    delay(100);
    cold.write(90);
    colddelay = colddelay - 100;
    delay(2000);
  }
  else if (tempc > tempvarhigh) {
    cold.write(180);
    delay(100);
    cold.write(90);
    colddelay = colddelay + 100;
    delay(2000);
  }
}
void turnoff() {
  // Get Temp Shower Head
  temphigh = analogRead(temphead);
  pretempf = map(temphigh, lowvol, highvol, lowc, highc);
  tempc = (pretempf - 32) * 5 / 9;
  // Print Shower Temp
  lcd.setCursor(9, 1);
  lcd.print(tempc);
  // Close Valve
  valve.write(0);
  delay(valvedelay);
  valve.write(90);
  // Close Hot
  hot.write(0);
  delay(hotdelay);
  hot.write(90);
  // Close Cold
  cold.write(0);
  delay(colddelay);
  cold.write(90);
  // Reset All States
  state = 0;
  templow = 0;
  temphigh = 0;
  tempc = 0;
  colddelay = 400;
  delay(1000);
  // Update ThingSpeak FINAL
  String headtemperature = String(tempc, DEC);
  String runtime = String(state, DEC);
  updateThingSpeak("field1=" + runtime + "&field2=" + headtemperature);
  delay(5000);
  // Clear LCD
  lcd.clear();
}
